Storefront Glazing Systems
Storefront Glazing Systems. 5 Series for High Performance
Designed for business and homes, our glass and aluminum storefront glazing series have a lot to offer. Including a complete line of storefront stock lengths, each glazing system makes it easy to get you up and running. Extruded in-house from 6063-T5 aluminum alloy, these storefront materials provide strength and durability you can rely on. Available in clear or bronze anodized finishes, our framing sections coordinate seamlessly with a variety of exterior and interior front entries.
At PRL, our storefront glazing systems deliver top performance. Featuring traditional center or front set glass, these components can be fit with insulated or laminated glass in addition to a wide range of glass types. When used with high performing glass, our storefronts yield a number of structural and energy benefits. Hurricane impact and seismic design requirements can be met and indoor temperatures, as well as air and water infiltration, are better managed.
Affording versatility and adaptability, our framing materials are manufactured to be compatible with an assortment of storefront products. Meeting virtually any architectural specification, our center and offset series can be used with our aluminum doors, storefront hardware, handles and glass types. Functional and offering numerous design options, you can’t go wrong with our storefront glazing systems.
Center Glazing Systems
Explore PRL of California’s center glazed systems and create premium quality glass and aluminum storefronts. Meeting industry standard, and higher, performance requirements, these framing sections are ideal for industrial and residential applications. Furnishing three flexible systems with a variety of beneficial features, we can meet your passageway needs.
205, 400 & 450 Center Glazed Systems: Features, Specs & Compatible Products
250 Storefront Series Center Glazed System:
- Features:
- Cost effective center glazing system
- Increases energy efficiency
- Designed specifically for insulated glass units
- Specifications:
- Glass thickness: 1″
- Glass pocket width: 1 ¼”
- Framing sections: 2″ x 4 ½”
Compatible 250 Series Products:
- Wide array of aluminum doors using a filler insert
- Large assortment of storefront hardware
- Included Storefront Stock Lengths:
- Head & sill assemblies
- Horizontal assembly
- Corner post
- Wall jamb
400 Storefront Series Center Glazed System:
- Features:
- Center glazing system with optimal versatility
- Meets industry standard performance requirements
- Accommodates nearly any storefront design
- Specifications:
- Glass thickness: ¼”
- Glass pocket width: ½”
- Framing sections: 1 ¾” x 4″
Compatible 400 Series Products:
- All aluminum doors with single or double action hardware
- All standard storefront hardware
- All storefront glass types
- Included Storefront Stock Lengths:
- Head, sill & horizontal assemblies
- Corner post
- Door jamb
450 Storefront Series Center Glazed System:
- Features:
- Flexible, center glazing system for exterior applications
- Meets higher performance standards
- Also suitable for interior applications
- Specifications:
- Glass thickness: ¼”
- Glass pocket width: ½”
- Framing sections: 1 ¾” x 4″
Compatible 450 Series Products
- All aluminum doors with single or double action hardware
- All standard storefront hardware
- All storefront glass types
- Included Storefront Stock Lengths:
- Head, sill & horizontal assemblies
- Corner post
- Vertical mullion
Offset Glazing Systems
For offset glazed systems that combine the best of form and function, shop at PRL of the City of Industry. Featuring IG unit compatibility and adjustable glass inserts for custom applications, these framing materials are a must-have. Designed for exterior and interior front entrances, we supply two interchangeable systems to create attractive, energy efficient glass and aluminum storefronts.
251 & 251DT Offset Glazed Systems: Features, Specs & Compatible Products
251 Storefront Series Offset Glazed System:
- Features:
- Offset glazing system designed to reduce energy costs
- Manufactured specifically for insulated glass units
- Equipped with adjustable glass inserts for custom applications
- Specifications:
- Glass thickness: 1″
- Glass inserts: Can be positioned inward or outward
- Framing sections: 2″ x 4 ½”
Compatible 251 Series Products:
- Most aluminum doors
- Large selection of storefront hardware
- Included Storefront Stock Lengths:
- Head assembly
- Sill assembly
- Horizontal assembly
- Vertical mullion
251DT Storefront Series Offset Glazed System:
- Features:
- High performance commercial grade offset glazing system
- Thermally broken frames prevent heat transfer
- Weatherstripping minimizes air infiltration
- Specifications:
- Glass thickness: 1″
- Glass inserts: Can be positioned inward or outward
- Framing sections: 2″ x 4 ½”
Compatible 251DT Series Products:
- Most aluminum doors
- Huge array of storefront hardware
- Included Storefront Stock Lengths:
- Head assembly
- Sill assembly
- Horizontal assembly
- Vertical mullion
Increase Energy Efficiency! Quote Our Storefront Glazing Systems!
Shop storefront glazing systems at PRL! Our center and offset series have a lot to offer. Get in on the benefits today!
